Haihao Group Supplied MSS SP-97 and ASME B16.11 Forged Fittings for Singapore Project
Haihao Group recently completed the manufacturing and delivery of a large batch of forged piping components for a Singapore customer. The order covered a wide range of branch outlets, socket weld fittings, threaded fittings, reducers, couplings, caps, and other small-diameter pressure fittings manufactured according to MSS SP-97 forged fittings standards and related specifications.
The supplied products included ASTM A105 carbon steel fittings, ASTM A350 LF2 CL1 low-temperature service fittings with NACE requirements, and ASTM A234 WPB/A420 WPL6 reducers. These components were supplied with strict material control, heat treatment requirements, impact testing requirements, and customer-specified marking methods.
MSS SP-97 forged fittings and ASME B16.11 socket weld fittings supplied by Haihao Group
Order Overview of Forged Piping Components
The Singapore order included butt weld branch outlets, socket weld branch outlets, socket weld elbows, tees, couplings, threaded caps, and concentric reducers. All products required pin marking instead of laser engraving according to customer requirements.
| Product | Size | Standard | Material | Special Requirement |
| Butt Weld Branch Outlet | 3″ × 8″ STD × S-20 | MSS SP-97 | ASTM A105 | Pin Marking, Clear Coating |
| Socket Weld Branch Outlet | 1″ × 4″ 6000# | MSS SP-97 | ASTM A350 LF2 CL1 | NACE Requirement |
| Socket Weld Elbow 90° | 1″ / 1.5″ 6000# | ASME B16.11 | ASTM A105 | Forged Construction |
| Socket Weld Coupling | 0.5″ – 1.5″ 6000# | ANSI B16.11 | ASTM A105 | Clear Coating |
| Threaded Cap | 0.75″ – 1.5″ 3000#/6000# | ANSI B16.11 | ASTM A105 | Pin Marking |
| Concentric Reducer | 0.75″ × 0.5″ / 3″ × 1″ | MSS SP-95 | ASTM A234 WPB / A420 WPL6 | NACE Available |
Wide Range of MSS SP-97 Branch Outlet Fittings
Branch outlet fittings are widely used in piping systems where a smaller branch connection is required from the main pipeline. The Singapore project included both butt weld and socket weld branch outlets in various sizes, including 0.75 inch, 1 inch, 1.5 inch, 2 inch, 3 inch, and 6 inch configurations.
The MSS SP-97 forged fittings supplied by Haihao Group were manufactured with accurate dimensions and controlled material properties to meet the requirements of industrial piping systems. These fittings are commonly applied in oil & gas, chemical processing, power generation, and pressure equipment industries.
Material Control for A105 and A350 LF2 CL1 Components
Material selection was a key requirement for this project.
For ASTM A105 carbon steel components, Haihao Group provided material traceability and matching test samples according to customer requirements. For ASTM A350 LF2 CL1 fittings, additional low-temperature service requirements were applied:
- Chemical composition control:
- Carbon (C) ≤ 0.23%
- Sulfur (S) ≤ 0.020%
- Phosphorus (P) ≤ 0.025%
- Carbon equivalent (CE) ≤ 0.43%
- NACE requirements:
- Sulfur content below 0.02%
- Hardness maximum: 197 HBW
- Impact test temperature: -46℃
- Impact energy: 27J average, minimum 20J
Heat treatment was carried out for A350 LF2 CL1 products to ensure the required mechanical properties and low-temperature performance.
Socket Weld Fittings Manufactured According to ASME B16.11
Besides branch outlets, the order also included socket weld elbows, socket weld tees, and couplings manufactured according to ASME B16.11 forged fittings requirements.
These fittings were produced in ASTM A105 and ASTM A350 LF2 CL1 materials with pressure classes including 3000#, 6000#, and 9000#. The combination of forged construction and controlled machining provides reliable strength for high-pressure piping connections.
Quality Control and Customer-Specified Marking
For this Singapore shipment, Haihao Group followed strict inspection procedures throughout manufacturing:
- Material verification and traceability
- Chemical composition inspection
- Heat treatment control
- Hardness testing
- Impact testing for low-temperature materials
- Dimensional inspection
- Surface protection with clear coating
All products were required to use pin-type marking. Laser engraving was not permitted according to customer specifications, ensuring compliance with project requirements.
Haihao Group – Reliable Supplier of Industrial Forged Fittings
With extensive experience in pipeline components, Haihao Group provides forged fittings, butt weld fittings, flanges, and customized piping solutions for global customers.
From MSS SP-97 forged fittings to ASME B16.11 socket weld fittings, Haihao Group focuses on accurate manufacturing, material reliability, and professional export service for demanding industrial projects.
Contact Haihao Group for your next forged fitting and piping project.
