Haihao Group Dispatches Heavy-Wall MSS SP-75 WPHY65 Eccentric Reducers to UAE
Haihao Group has completed a specialized dispatch of large-diameter, high-yield butt-weld fittings for an offshore oil and gas pipeline project in the United Arab Emirates (UAE). The shipment features heavy-wall, single-seam eccentric reducers engineered to meet severe service criteria, including ultra-low sulfur content, strict non-destructive testing, and low-temperature toughness.
Project Order Specification Manifest
Partnering with an certified MSS SP-75 WPHY65 eccentric reducer supplier ensures exact wall thickness transitions and full compliance with high-yield pipeline codes. Below is the technical specification of the dispatched cargo:
42″ x 36″ Eccentric Reducer (Single Seam): Wall Thickness: 22.23 mm x 19.05 mm | ASTM A860 Grade WPHY65-W | Standard: MSS SP-75 | Finish: Black Anti-Corrosion Paint.
36″ x 28″ Eccentric Reducer (Single Seam): Wall Thickness: 19.05 mm x 14.27 mm | ASTM A860 Grade WPHY65-W | Standard: MSS SP-75 | Finish: Black Anti-Corrosion Paint.
42″ x 28″ Eccentric Reducer (Single Seam): Wall Thickness: 22.23 mm x 14.27 mm | ASTM A860 Grade WPHY65-W | Standard: MSS SP-75 | Finish: Black Anti-Corrosion Paint.
28″ x 18″ Eccentric Reducer (Single Seam): Wall Thickness: 14.27 mm x 9.53 mm | ASTM A860 Grade WPHY65-W | Standard: MSS SP-75 | Finish: Black Anti-Corrosion Paint.
MSS SP-75 WPHY65 eccentric reducer manufacturer shipping single seam butt weld reducers to UAE
Metallurgical Excellence & Low-Temperature Impact Integrity
High-yield oil and gas transport lines operating in demanding environments require stringent material control. Every MSS SP-75 WPHY65 eccentric reducer in this consignment was manufactured from clean-steel chemistry featuring ultra-low sulfur levels (S < 0.003%) to mitigate sulfide stress cracking (SSC) and hydrogen-induced cracking (HIC).
To verify mechanical performance and weld joint reliability, all fittings underwent controlled Post-Weld Heat Treatment (PWHT) and 100% Radiographic Testing (RT / Radiography) on single-seam longitudinal welds. Furthermore, heat lots were subjected to Charpy V-Notch (KCV) impact testing at -46°C, guaranteeing high fracture toughness under extreme sub-zero shock loads.
Surface Protection & Export Logistics
As an experienced MSS SP-75 WPHY65 eccentric reducer manufacturer, Haihao Group enforced multi-layer protective packaging for international maritime shipment:
Component surfaces received a heavy-duty black anti-corrosion coating to resist salt mist during transit and storage.
Beveled ends were fitted with heavy-duty edge protectors to guard against mechanical distortion during handling.
Complete EN 10204 3.1 certification was provided, including RT films, PWHT charts, heat analysis (S < 0.003%), and -46°C impact test reports.
Working with a reliable MSS SP-75 WPHY65 eccentric reducer manufacturer streamlines procurement for heavy-wall, high-yield pipeline fittings.
Contact Us for UAE Project Inquiries
Looking for certified ASTM A860 WPHY65 fittings or custom large-bore single-seam reducers for your energy infrastructure projects? Partner with an industry leader. Contact the Haihao Group technical sales division today for rapid quotations and engineering support.
